Voltage: 1-380V

Insulation Material: Silicone

Thickness: 1-3MM(Conventional 1.5MM)

Static Power Deviation: +/-5% (According To Customer Requirements)

Withstand Voltage: Withstand Voltage AC 1500V 5MA/min

Insulation: Insulation DC 1000V >100MΩ

Temperature: -40°C - 250°C (Below 200°C For Long-term Use)

Installation Method: Adhesive Paste,Installation Through mechanical Installation Holes

Solder Joint Insulation Treatment: Epoxy, Silicone Pressure

Temperature Control Method: Adjustable Thermostat, Temperature Fuse, Temperature Control Switc

Get An Instant Quote
The design of silicone rubber heaters can be customized according to the ever-changing needs of customers to ensure a perfect match between the heating element and the customer's product, thereby enhancing efficiency. The first step is to design the shape of the silicone rubber based on the customer's product and calculate the heating area. Then, the silicone rubber can be cut according to the drawn shape, reducing costs and optimizing the performance of the heating element.

Silicone rubber is a durable and elastic material that can withstand high-temperature heating. It exhibits excellent electrical insulation properties. The heating element is embedded within the silicone rubber to ensure even heat distribution on the surface. It aims to provide consistent and uniform heat distribution on its surface, making it an ideal choice for various industrial and commercial applications.

Specifications of silicone rubber heaters

The size range of silicone rubber heaters is from 1" x 1" to 18" x 24". If customers require larger heater sizes, we can conduct research and design to transition from etched elements to wire elements.

We also provide various heating elements for silicone rubber heaters, such as Stainless Steel 304, CuNi44, and Inconel600. These elements have excellent dielectric performance and are suitable for various working environments. Here are the main specifications of silicone rubber heaters:

· Maximum power density: 60 W/in²
· Maximum operating temperature: 250°C
· Minimum operating temperature: -40°C
· Power tolerance: ±10%

· Dielectric strength: 1000 VAC

silicone rubber heater

Performance of silicone rubber heaters

Uniform heating: Silicone rubber heaters provide uniform heat distribution, ensuring consistent temperature across the entire surface. This feature is crucial for applications that require precise and uniform heating, such as food processing or medical devices.

Fast heating time: The design of the heating element facilitates rapid heat transfer, allowing it to quickly reach the desired temperature. This property is beneficial for applications where time is a critical factor.

Customizable power and voltage: The heating element can be customized to meet specific power and voltage requirements, ensuring compatibility with various power sources and integration into different systems.
Temperature control: The heating element can be equipped with built-in temperature control mechanisms, such as thermostats or sensors, to maintain accurate and consistent heating. This control enables precise temperature regulation and prevents overheating.

Durability: The silicone rubber material used in the heating element exhibits excellent durability, wear resistance, and lifespan, even in harsh environments. It is also resistant to moisture, chemicals, and UV radiation, thereby enhancing its performance and lifespan.
