Series PFS High Voltage Tube Resistors
聽
PFS High Voltage Tube Resistor is a type of ceramic composition thick film resistor by silkscreen printing a layer of paste or slurry to achieve conductivity, thick film resistors are widely used and play a very important role in high voltage circuits, which serves as basic accessories in the power and electrical industry, basic physics research, national defense technology and other fields. Because of its high voltage and wide range of resistance properties, it is commonly used in high-voltage devices such as in high-frequency converters, high-voltage power supplies, detection equipment, high voltage soft starter.
聽
聽PFS Series聽Features
路聽 High power density
路聽 Excellent HF characteristics
路聽 Anti-pulse, High-temperature appliance
路聽 Anti-pulse, High stability
Typical Application
路聽 Broadcasting transmitting device
路聽 Rader system
路聽 Loading resistor
路聽 High and medium frequency devices
聽
Special Features
|
Model |
Rated power(W) |
Dimensions |
||
|
D |
L |
d |
||
|
PFS30 |
30 |
14.5 |
156 |
M4 |
|
PFS50 |
50 |
27.0 |
130 |
M6 |
|
PFS100 |
100 |
30.5 |
158 |
M6 |
|
PFS150 |
150 |
27.0 |
200 |
M6 |
|
PFS180 聽 |
180 |
30.5 |
273 |
M6 |
|
PFS200 |
200 |
30.5 |
303 |
M6 |
|
PFS300 |
300 |
30.5 |
373 |
M6 |
|
PFS400 |
400 |
43.0 |
412 |
M8 |
聽聽
聽
聽
聽
special dimensions tube high power reside stor can be made聽according to customer鈥檚 requirements
聽
Specification
|
TEST ITEM |
SPECIFICATIONS |
|
Resistance Range |
1惟锝20M惟 |
